NEW AUTOID Pad acquisition terminal

Mobile tablet solutions made easy

NEW AUTOID Pad is compact and industrial tablet with portable and industrial protective design, it concentrates on providing more cost-effective mobile solutions to enterprises. Which adopts 7”IPS full-view high definition screen, high-end capacitive touch, support finger touchable operation-with or without gloves even wet, Cortex-A53 Quad Core 1.2GHz, Android 5.1 OS, support shortcut keys operation, Multiple options of barcode, NFC, Camera, GPS, RS485, Wi-Fi, 4G, Bluetooth, OTG, etc, Fully meet the demands on the informatization of industrial applications.

Excellent performance of man-machine interaction:

Adopt7” industrial display, 1280*800 high definition, 5-place touchable, it’s convenient to see more details of reports clearly, 11mm industrial and thin body, main machine adopts streamlined design, only weighs 485g, comfortable grip, easy to carry.

All-weather application design:

Fully meet the operations under the heat, cold, rain and snow and other harsh environments, and satisfy the operation for a long time.

Leading performance:

Support2.4/5Gdual-band WIFI simultaneously, optimized roaming design, solve the problems of roaming/electromagnetic interference/offline in warehouse. N6630 barcode scan engine, Special rapid deployment technology of camera, safety management mechanism and remote management, Support 4G and NFC.

Remote management and security design:

Double security solutions, App management of installation rights, mobile manager with our independent intelligent property right to ensure data security, Triple management design, mass installation of configurations and softwares, online update, remote management and maintenance.

Strict reliable design:

Follow the “reliability from the inside to outside” design concept, strengthen the device overall rigidity, meet the strict industry standards, through multi-stringent reliability test to ensure the product stability, great ly avoid all kinds of accidents in industrial environments.

Operating system(OS):Android 5.1
Processor(CPU):CortexTM-A53 Quad core 1.2GHz
User storage space:none
User memory expansion:Micro SD Card, 32GB SDHC compatible

Size:123mm(H)×199mm(W)×15mm(T) (21mm at barcode engine)
Weight:485g (Including battery depends on different configurations)
Notice:Sound, vibrator, LED indicator light
Display type:7” full-view LCD, 1280(H)×800(W) (WXGA)
Touch screen:capacitive, touch-with or without a thick glove / with dry or wet hand, touch open
LED backlight:LED backlight Keyboard option:6 main keys, 3 side keys
Audio options:Built-in double speakers, built-in microphone, the 3.5 mm stereo headset interface
Sensor:Acceleration sensor, light sensor, electronic compass and gyroscope

Drop specifications:1.2m(concrete)
Seal protection grade:IP65
Humidity:5% to 95% RH non-condensing
Working temperature:-20℃ to +50℃
Storage temperature:-40℃ to +60℃
Electrostatic discharge(ESD):±15kV Air discharge, ±8kV direct discharge
Earthquake resistance and impact resistance:none

Options 1.One dimensional laser scanning engine:none
Options 2.Two dimensional image engine
Options 3.RFID read/write:HF
Options 4.GPS geographical position information acquisition:5-10meter(OPEN SKY)

Options 5.Image acquisition:Front Camera 2.0 megapixel  Rear Camera 8.0 megapixel
Options 6.Temperature measurement:none
Options 7.Fingerprint acquisition:none
Options 8.License acquisition:none

Options 1.Wireless LAN:WIFI: IEEE 802.11a/b/g/n (2.4G/5G dual frequency WIFI)
Options 2.Wireless wide area network:All Network: 7 mode 15 frequency
Options 3.Wireless personal area network:Bluetooth 4.0 (Dual-mode, support BLE)

Battery:Non-removable 6200mAH rechargeable li-ion battery

The handheld equipment warranty:12 months since the date of delivery in the case of non-artificial damage

The host charger 5V/2.5A×1

Micro USB cable×1

Mounting bracket

Single-slot multifunctional charging base

Tail serial cable

Hand belt + Hand belt buckle

RS485 cable

Magnetic suction cable

Mounting bracket

Vehicle mount


Touch pen
